Discover the ultimate in truss engineering with the Titan AV 290mm Cube Truss. Designed for small to medium-sized productions, this truss offers unmatched strength, versatility, and ease of assembly.

Why Titan AV 290mm Cube Truss?

Built to Last: Crafted from high-quality 6082-T6 aluminium and assembled by master welders, our box truss ensures durability and strength. It's not just about holding equipment overhead; it's about trusting that your truss will perform flawlessly every time.

Safety First: Your safety is paramount. That’s why Titan AV truss undergoes rigorous testing by independent engineers at the University of Southern Queensland. With a 1.5 factor rating built into our load tables, you can rig with confidence knowing your truss won’t let you down.

Versatile Design: The innovative conical coupling system makes assembly quick and easy, saving you valuable setup time. The 290mm Box Truss is multipurpose, ideal for video walls, moving heads, heavy lighting, display panels, and more.

Customisation Options: Stand out from the crowd with our custom colour powder coating service. Choose from a variety of colours to match your brand or event theme. This optional extra allows you to personalise your truss and make a lasting impression.

Trusted Nationwide: From schools and universities to large-scale festivals and multinational events, Titan AV truss is trusted by professionals across Australia. Join a community of AV enthusiasts who rely on Titan AV for their most important events.

Key Features:

Australian Engineering Certification : Independently tested for maximum safety.
Complete Rigging Set: The package includes 8 half spigots (M12 bolts), 8 pins, and 8 clips for secure assembly. Please note that our 290mm Cube Truss comes with connectors for two sides only. Additional half spigots, truss pins and clips are available for purchase on our website.
Wide Range of Applications: Perfect for stage productions, venues, exhibitions, clubs, and churches.
Custom Colours Available: Contact us for a quote on powder coating options.
Warranty: Enjoy peace of mind with our 2-year warranty.

Specifications:

Length: 0.3m
Weight: 8.2kg
Material: 6082-T6 Aluminium
Finish: Milled
Main Tube: 50mm (3mm wall thickness)
Braces: 25mm (2mm wall thickness)

290mm Box Truss: Safety Load Table

Span	Uniformly Distributed Load (UDL)	Deflection	Centre Point Load (CPL)	Deflection
M	KG/M	MM	KG	MM
3	320	10	1260	12
4	285	24	1080	19
5	290	50	960	29
6	175	60	870	42
7	110	69	780	57
8	78	80	720	720
9	55	90	600	89
10	40	100	600	99
11	30	109	500	109
12	24	124	420	118

Embrace the Titan AV difference and elevate your AV setups with our 290mm Cube Truss. Join our community of passionate AV enthusiasts and experience the quality and reliability that Titan AV brings to every event. Get in touch with us today to learn more!
